PRB-420

MRI and Cryogenic Temperature Sensing

OSENSA’s fast response PRB-420 contact temperature probes provide accurate and reliable temperature sensing for a variety of life sciences, microwave and laboratory research applications requiring immunity to high intensity electro-magnetic fields and RF energy. These probes are constructed with an exposed sensing element on the tip and are ideal for MRI electrode, cryogenic tissue, or electronics package sensing. They can handle temperatures from -95°C up to 180°C while providing extremely fast response times.

Product Specs

Measurement Range

-40°C to 150°C

Measurement Accuracy

± 0.15°C

Immersion Response Time Constant

0.25 s

Stability

± 0.02°C

Peak To Peak Noise 1s Averaging

± 0.02°C

Jacket

Polyimide & ETFE

Bend Radius

50mm

Tip Diameter

700µm

Compatible Products

Temperature Transmitters

MRI, Microwave, Semiconductor, HIFU

FTX-300-LUX+

Number Of Channels:

3

Analog Output:

3

Digital Interface:

USB & Isolated RS-485

Temperature Transmitters

MRI, Microwave, Semiconductor, HIFU

2 Ch, USB, 4-20mA, RS-485

Number Of Channels:

2

Analog Output:

2

Digital Interface:

USB & Isolated RS-485

Temperature Transmitters

MRI, Microwave, Semiconductor, HIFU

1 Ch, USB, 4-20mA, RS-485

Number Of Channels:

1

Analog Output:

1

Digital Interface:

USB & Isolated RS-4851

Temperature Transmitters

MRI, Microwave, HIFU

3 Ch, High Gain for weaker signals

Number Of Channels:

3

Analog Output:

3

Digital Interface:

USB & Isolated RS-485

Temperature Transmitters

MRI, Microwave, HIFU

2 Ch, High Gain for weaker signals

Number Of Channels:

2

Analog Output:

2

Digital Interface:

USB & Isolated RS-485

Temperature Transmitters

MRI, Microwave, HIFU

1 Ch, High Gain for weaker signals

Number Of Channels:

3

Analog Output:

3

Digital Interface:

USB & Isolated RS-485

Temperature Transmitters

MRI

1 Ch, OEM Module SPI or Modbus

Digital Interface:

Serial Modbus (optional SPI)

Measurement Range:

-40 to +200°C

Measurement Accuracy:

-20 to +85°C

Temperature Transmitters

MRI

Handheld Fiber Optic Signal Conditioner

Digital Interface:

USB-mini

Measurement Range:

-40°C to +120°C

Resolution:

0.01°C
